Parse Trees in ANTLR

So what if we want to see our parse tree? We use the following command for that:

grun DelphiDFM file -tree test.dfm

And our output:

(file
    (block inherited frmActions : TfrmActions
        (propertyBlock Tag = (value 3))
        (propertyBlock Caption = (value 'hello'))

        (block inherited pnlTitle : TfrmTitleBar
            (propertyBlock Color = (value clWhite))
            (propertyBlock ParentBackground = (value False))
        end)

        (block inherited pnlError : TfrmError
            (block inherited lblMessage : TcxLabel
                (propertyBlock AnchorY = (value -18))
                (propertyBlock FloatAnchorY = (value 18.7283))
            end)
        end)

        (block object gvListUser : TcxGridDBColumn
            (propertyBlock Caption = (value 'Test'))
            (propertyBlock DataBinding.FieldName = (value 'TestUser'))
            (propertyBlock Properties.ListColumns = (value
                (collectionItems < (item
                                        item
                                            (propertyBlock FieldName = (value 'fullName'))
                                            (propertyBlock Fixed = (value True))
                                            (propertyBlock Width = (value 100))
                                        end) >)))
            (propertyBlock Properties.Alignment.Vert = (value taVCencter))
            (propertyBlock Height = (value 20))
            (propertyBlock Properties.DateButtons = (value [btnToday]))
        end)

        (block object testItemHchy : TestItemHchy
            (propertyBlock Properties.ListColumns = (value
                (collectionItems < (item
                                        item
                                            (propertyBlock Fixed = (value True))
                                            (propertyBlock Width = (value 80))
                                        end)
                                    (item
                                        item
                                            (propertyBlock Width = (value 200))
                                            (propertyBlock FieldName = (value 'testing'))
                                        end) >)))
            (propertyBlock Width = (value 282))
        end)

        (block inherited testFields : TestFields
            (propertyBlock Indexes = (value
                (collectionItems < >)))
            (propertyBlock SortOptions = (value []))
            (propertyBlock OtherSortOptions = (value [test1, test2, test3]))
        end)

        (block inherited testMultipleInheritance : TestMultipleInheritance
            (block inherited inhOne : InhOne
                (block inherited inhTwo : InhTwo
                    (block inherited inhThree : InhThree
                        (block object deepObj : DeepObj
                            (propertyBlock Height = (value 10))
                            (propertyBlock Width = (value 20))
                            (propertyBlock Top = (value 30))
                        end)
                    end)
                end)
            end)
        end)
    end)
<EOF>)

NOTE: The output above was manually modified with newlines for readability purposes, to ultimately demonstrate the presence of hierarchy.

The real output is actually a continuous line, and looks like this:

(file (block inherited frmActions : TfrmActions (propertyBlock Tag = (value 3)) (propertyBlock Caption = (value 'hello')) (block inherited pnlTitle : TfrmTitleBar (propertyBlock Color = (value clWhite)) (propertyBlock ParentBackground = (value False)) end) (block inherited pnlError : TfrmError (block inherited lblMessage : TcxLabel (propertyBlock AnchorY = (value -18)) (propertyBlock FloatAnchorY = (value 18.7283)) end) end) (block object gvListUser : TcxGridDBColumn (propertyBlock Caption = (value 'Test')) (propertyBlock DataBinding.FieldName = (value 'TestUser')) (propertyBlock Properties.ListColumns = (value (collectionItems < (item item (propertyBlock FieldName = (value 'fullName')) (propertyBlock Fixed = (value True)) (propertyBlock Width = (value 100)) end) >))) (propertyBlock Properties.Alignment.Vert = (value taVCencter)) (propertyBlock Height = (value 20)) (propertyBlock Properties.DateButtons = (value [btnToday])) end) (block object testItemHchy : TestItemHchy (propertyBlock Properties.ListColumns = (value (collectionItems < (item item (propertyBlock Fixed = (value True)) (propertyBlock Width = (value 80)) end) (item item (propertyBlock Width = (value 200)) (propertyBlock FieldName = (value 'testing')) end) >))) (propertyBlock Width = (value 282)) end) (block inherited testFields : TestFields (propertyBlock Indexes = (value (collectionItems < >))) (propertyBlock SortOptions = (value [])) (propertyBlock OtherSortOptions = (value [test1, test2, test3])) end) (block inherited testMultipleInheritance : TestMultipleInheritance (block inherited inhOne : InhOne (block inherited inhTwo : InhTwo (block inherited inhThree : InhThree (block object deepObj : DeepObj (propertyBlock Height = (value 10)) (propertyBlock Width = (value 20)) (propertyBlock Top = (value 30)) end) end) end) end) end) end) <EOF>)

Its contents are the same as the edited example preceding it, and still identifies hierarchy correctly; notice the end closures at the end of the output.

Tree Visualization

Thankfully, to simplify our lives, ANTLR provides a graphical representation of trees. The test is very simple:

grun DelphiDFM file -gui test.dfm

The output:

This gives us a much easier to read output of our parse tree.

Notice that:

• hierarchy is correctly represented.
• each block correclty begins and ends.
• we correctly represent positive and negative values for both integers and floating-point values.
• we have correctly accounted for sub-properties.
• item list syntax for collection properties correctly begin and end.
• empty item lists and arrays are correctly parsed.
• we even tested deep hierarchy, just to be sure.

Next up, we'll take a look at some additional useful features of ANTLR, and mention some important methodologies to keep in mind.
